High Quality 382 Piece Imperial Nitrile Rubber O Ring Kit Comprising
The Following O'Rings
Sizes shown are in mm (although this is an imperial sized kit), the bold
numbers are the individual part numbers. There are 30 sizes in this kit.
| 2.90 x 1.78
20 off 2-006 | 3.68x1.78
20 off 2-007 | 4.47 x 1.78
20 off 2-008 | 5.28 x 1.78
20 off 2-009 | 6.07 x 1.78
20 off 2-010 | | 7.65 x 1.78
20 off 2-011 | 9.25 x 1.78
20 off 2-012 | 9.20 x 2.62
13 off 2-110 | 10.77 x 2.62
13 off 2-111 | 12.37 x 2.62
13 off 2-112 | | 13.95 x 2.62
13 off 2-113 | 15.55 x 2.62
13 off 2-114 | 17.12 x 2.62
13 off 2-115 | 18.72 x 2.62
13 off 2-116 | 18.64 x 3.53
10 off 2-210 | | 20.22 x 3.53
10 off 2-211 | 21.82 x 3.53
10 off 2-212 | 23.39 x 3.53
10 off 2-213 | 24.99 x 3.53
10 off 2-214 | 26.57 x 3.53
10 off 2-215 | | 28.17 x 3.53
10 off 2-216 | 29.74 x 3.53
10off 2-217 | 31.34 x 3.53
10 off 2-218 | 32.92 x 3.53
10 off 2-219 | 34.52 x 3.53
10 off 2-220 | | 36.09 x 3.53
10 off 2-221 | 37.69 x 3.53
10 off 2-222 | 37.47x5.33
7 off 2-325 | 40.64 x 5.33
7 off 2-326 | 43.82 x 5.33
7 off 2-327 |
The kit is supplied in a handy storage box with location T spindles and sunken
cavities for the simple location of the correct sized rings.
No more messy jumbled up boxes.
Nitrile rubber is both petrol and oil / hydraulic oil resistant and is suitable for
potable water applications too.
The rubber is of 70 deg shore hardness.
Kit is manufactured to BS1806 standard
Ideal for the mororcycle and car enthusiasts.
|
