£6.18
ex VAT
Price Breaks
| Quantity | Prices |
|---|---|
| 9+ | £5.50 each |
| 19+ | £5.19 each |
| 29+ | £5.13 each |
| 39+ | £5.07 each |
| 49+ | £5.01 each |
| 69+ | £4.95 each |
| 99+ | £4.64 each |
In Stock
| d | = | 0.197 inch |
| D | = | 0.276 inch |
| B | = | 0.315 inch |
| c1 min | = | 0 inch |
| c1 max | = | 0.02 inch |
| c2 min | = | 0.01 inch |
| c2 max | = | 0.04 inch |
| a | = | +8 20 degrees |
| Tolerance shaft | = | f7 |
| Tolerance housing | = | H7 |
| Basic dynamic load rating - radial direction ( C ) | = | 3.198112 lbf |
| Basic static load rating - radial direction ( C0 ) | = | 9.999104 lbf |
| Specific Dynamic Load Factor ( K ) | = | 11603.019 psi |
| Specific Static Load Factor ( K0 ) | = | 36259.435 psi |
| Factor depending on material and bearing type | = | 480 KM |
| Permissable Sliding Velocity ( v ) | = | min. 0 ft/min |
| Permissable Sliding Velocity ( v ) | = | max. 393.701 ft/min |
| Coefficient of Friction ( y ) | = | min. 0.03 |
| Coefficient of Friction ( y ) | = | max. 0.25 |
| Imperial Weight | = | 0.015 lbs |
