SKU: 50AT5/545
50AT5/545 ContiTech Standard Synchroflex Timing Belt 50mm Width 5mm Pitch 109 Teeth
50AT5/545 ContiTech Standard Synchroflex Timing Belt 50mm Width 5mm Pitch 109 Teeth
Regular price
£61.85
ex VAT£74.22inc. VAT
Regular price
Sale price
£61.85
ex VAT£74.22
inc. VAT
In stock
Price Break
3+
£55.05
5+
£51.95
10+
£51.34
15+
£50.72
20+
£50.10
30+
£49.48
40+
£46.39
50+
£45.77
60+
£45.15
75+
£44.53
100+
£43.30
Description
Description
AT Standard SYNCHROFLEX® Timing Belts: This belt is manufactured by ContiTech, specialists in rubber and plastics technology. This Synchroflex belt is a truly endless belt, suitable for AT pulleys.
Standard Synchroflex belts consist of just two components, a wear-resistant Contilan carcass and high-grade endless steel wire tension members. This construction provides high flank load capacity and low elastic elongation which makes them unsurpassed for quality and accuracy.
Benefits: High power AT profile, low elastic elongation and high flank load capacity.
- Brand / Quality:
- ContiTech - High Quality
- Thickness:
- 1.5mm
- Belt Width Approx:
- 50mm
- Belt Length Approx:
- 545mm
- Number of Teeth:
- 109
- Item Type:
- AT5 Standard Timing Belt
Technical
Technical
| No of Teeth | 109 |
|---|---|
| Belt Width | 50mm |
| Belt Pitch | 5mm (AT5) |
| Belt Length | 545mm |
| Belt Thickness (hs) | 1.5mm |
| Tooth Height (ht) | 1.2mm |
| Tooth Pitch (t) | 5mm |
| Flank Angle (f) | 50 deg |
| Tension Member Loadings | 4200 N |
| Belt Weight (per metre) | 0.17kg |
