UCP206 Metric Cast Iron Two Bolt Pillow / Plummer Block Housing with 30mm Bore Insert
Equivalent to: NP30
£12.74
ex VAT
Price Breaks
| Quantity | Prices |
|---|---|
| 3+ | £11.47 each |
| 4+ | £10.83 each |
| 9+ | £10.19 each |
| 19+ | £9.56 each |
| 49+ | £8.92 each |
| 99+ | £8.28 each |
| 499+ | £7.64 each |
| 999+ | £6.37 each |
| 1999+ | £6.12 each |
| 2999+ | £5.99 each |
| 4999+ | £5.73 each |
In Stock
| d | = | 30mm |
| h | = | 42.9mm |
| a | = | 165mm |
| e | = | 121mm |
| b | = | 48mm |
| s2 | = | 21mm |
| s1 | = | 17mm |
| g | = | 18mm |
| w | = | 83mm |
| B1 | = | 38.1mm |
| n | = | 15.9mm |
| Bolt Size | = | M14 |
| Weight | = | 0.79 kg |
| Dynamic load | = | 1520 kgf |
| Static load | = | 1020 kgf |
| Rec max speed | = | 5300 rpm |
