AX Thin Series Needle Roller Thrust Bearings: Needle roller and cage thrust assemblies are a low profile high load thrust bearing assembly and can be used with the CP series thrust washers which are supplied separately. They are manufactured with an integrated washer and a uniform cage that reliably guides many needle rollers. The rollers are slightly relieved towards their outer edge to enable uniform load distribution and prevent any edge damage occurrence. Benefits: Cost-effective thrust solution, wide range, low profile, high load bearing.
Brand / Quality: Major Brand - High Quality Inside Diameter: 30mm Outside Diameter: 47mm Width: 2.8mm
Dc1
=
30mm
D
=
47mm
B1
=
2.8mm
Eb
=
32.7mm
Ea
=
42.4mm
Dynamic load
=
14.5 kN
Static load
=
57 kN
Speed rating in oil
=
6500 rpm
Mass
=
0.014 kg
Write a review
There are currently no reviews - but you could help other users and write one.
Write a Product Review
Major Brand AX3047 Thin Needle Roller Thrust Bearing 30x47x2.8mm
