3058032RSR Double Row Rubber Sealed Cam Roller Cylindrical Outer 17x47x17.5mm

Page Feedback?

SKU: 305803.2RSR.MB

£71.42 ex VAT

Price Breaks

Quantity	Prices
10+	£63.57 each
19+	£59.99 each
29+	£59.28 each
39+	£58.57 each
49+	£57.85 each
74+	£57.14 each
99+	£53.57 each

10+ £63.57 each
19+ £59.99 each
29+ £59.28 eachClick Here…

In Stock

Add to a Save List

Cam Rollers: Are special variants of deep groove ball bearings which have thicker outer races to allow for running in tracks as rollers where misalignment and shock loads may be present. They have the same characteristics as normal deep groove ball bearings, generally have seals although some unsealed versions are available and can also be used in place of standard bearings. They are available with parallel outside diameter or crowned (spherical) for applications where greater misalignment needs to be catered for.
Benefits: Tolerate high loads, shock loads, misalignment when running in tracks

Brand / Quality: Major Brand - High Quality
Inside Diameter: 17mm
Outside Diameter: 47mm
Width: 17.5mm
Seals / Shields: Rubber Sealed
Need Oil Seals?

Click Here

Need Viton Seals?

Click Here

Bore	=	17mm
Outside Diameter	=	47mm
Width	=	17.5mm
Max rad R	=	400mm
r1r2	=	0.6mm
Limiting speed	=	6000 rpm
Dynamic load as cam roller	=	14.6 kN
Static load as cam roller	=	9 kN
Dynamic load as bearing	=	13.8 kN
Static load as bearing	=	8.3 kN
Max radial load	=	19.3 kN
Max static load	=	27.5 kN
Weight	=	0.16 kg
