Loading…
£12.47
ex VAT
Price Breaks
| Quantity | Prices |
|---|---|
| 10+ | £11.10 each |
| 19+ | £10.47 each |
| 29+ | £10.35 each |
| 39+ | £10.22 each |
| 49+ | £10.10 each |
| 74+ | £9.97 each |
| 99+ | £9.35 each |
| 199+ | £9.23 each |
| 249+ | £9.10 each |
| 499+ | £8.98 each |
| 999+ | £8.73 each |
In Stock
| d | = | 20mm |
| D | = | 52mm |
| T | = | 16.25mm |
| a | = | 16mm |
| B | = | 15mm |
| C | = | 11mm |
| Ca min | = | 3mm |
| Cb min | = | 5mm |
| Da max | = | 45mm |
| Da min | = | 40mm |
| Db min | = | 48mm |
| d1 | = | 37.3mm |
| da max | = | 27mm |
| db min | = | 27mm |
| r1, 2 min | = | 1.5mm |
| r3, 4 min | = | 1.5 mm |
| ra max | = | 1.5mm |
| rb max | = | 1.5mm |
| Cr | = | 30500 N |
| C0r | = | 29500 N |
| e | = | 0.73 |
| Y | = | 0.82 |
| Y0 | = | 0.45 |
| Cur | = | 3350 N |
| nG | = | 14900 1/min |
| nB | = | 8400 1/min |
| kg | = | 0.174 kg |
