£3.51
ex VAT
Price Breaks
| Quantity | Prices |
|---|---|
| 10+ | £3.12 each |
| 19+ | £2.95 each |
| 29+ | £2.91 each |
| 39+ | £2.88 each |
| 49+ | £2.84 each |
| 74+ | £2.81 each |
| 99+ | £2.63 each |
| 199+ | £2.60 each |
| 249+ | £2.56 each |
| 499+ | £2.53 each |
| 999+ | £2.46 each |
In Stock
| d | = | 7mm |
| D | = | 19mm |
| B | = | 6mm |
| Dynamic load C | = | 2.34 kN |
| Static load Co | = | 0.95 kN |
| Fatigue load limit Pu | = | 0.04 kN |
| Reference speed | = | 85000 rpm |
| Limiting speed | = | 53000 rpm |
| Mass | = | 0.0075 kg |
| d1 | = | 11.1mm |
| D1 | = | 15.2mm |
| D2 | = | 16.5mm |
| r1r2 min | = | 0.3mm |
| da min | = | 9mm |
| Da max | = | 17mm |
| ra max | = | 0.3mm |
| Calc factor Kr | = | 0.025 |
| Calc factor | = | 13 |
