£621.49
ex VAT
Price Breaks
| Quantity | Prices |
|---|---|
| 10+ | £553.13 each |
| 19+ | £522.05 each |
| 29+ | £515.84 each |
| 39+ | £509.62 each |
| 49+ | £503.41 each |
| 74+ | £497.19 each |
| 99+ | £466.12 each |
| 199+ | £459.90 each |
| 249+ | £453.69 each |
| 499+ | £447.47 each |
| 999+ | £435.04 each |
In Stock
| d | = | 100mm |
| D | = | 170mm |
| H | = | 42mm |
| Dynamic load C | = | 465 kN |
| Static load Co | = | 1290 kN |
| Fatigue load limit Pu | = | 156 kN |
| Minimum load factor A | = | 0.16 |
| Reference speed | = | 2200 rpm |
| Limiting speed | = | 3600 rpm |
| Weight | = | 3.65 kg |
| d1 | = | 152.3mm |
| D1 | = | 127.5mm |
| B | = | 26.2mm |
| B1 | = | 36.3mm |
| C | = | 20.5mm |
| s | = | 58mm |
| r1r2 min | = | 1.5mm |
| da min | = | 130mm |
| db1 max | = | 107mm |
| db2 max | = | 107mm |
| Da max | = | 147mm |
| ra max | = | 1.5mm |
