FAG 23220E1AKMC3 X-life Spherical Roller Bearing with Taper Bore 100x180x60.3mm
Equivalent to: 23220KC3
What is C3? [Click Here]
£426.25
ex VAT
Price Breaks
| Quantity | Prices |
|---|---|
| 3+ | £379.36 each |
| 4+ | £358.05 each |
| 9+ | £353.79 each |
| 19+ | £349.53 each |
| 29+ | £345.26 each |
| 39+ | £341.00 each |
| 49+ | £319.69 each |
| 59+ | £315.43 each |
| 249+ | £311.16 each |
| 499+ | £306.90 each |
| 999+ | £298.38 each |
In Stock
| Dimensions | ||
| d | = | 100mm |
| D | = | 180mm |
| B | = | 60.3mm |
| r min. | = | 2.1mm |
| D1 | = | 156.7mm |
| ds | = | 4.8mm |
| ns | = | 9.5mm |
| da min. | = | 112mm |
| Da max. | = | 168mm |
| ra max. | = | 2.1mm |
| Loads, Speeds and Weights | ||
| Fatigue limit load | = | 60000 N |
| Limiting speed | = | 3600 rpm |
| Reference speed | = | 2410 rpm |
| Dynamic Load Rating | = | 550000 N |
| Static Load Rating | = | 660000 N |
| Weight | = | 6.33kg |
| Factors | ||
| e | = | 0.31 |
| Y1 | = | 2.15 |
| Y2 | = | 3.2 |
| Y0 | = | 2.1 |
| Matching Adaptor Sleeves | ||
| Sleeve No. | = | H2320 |
| Matching Withdrawal Sleeves | ||
| Sleeve No. | = | AHX3220 |
