£6.12
ex VAT
Price Breaks
| Quantity | Prices |
|---|---|
| 10+ | £5.44 each |
| 19+ | £5.14 each |
| 29+ | £5.08 each |
| 39+ | £5.01 each |
| 49+ | £4.95 each |
| 74+ | £4.89 each |
| 99+ | £4.59 each |
| 199+ | £4.53 each |
| 249+ | £4.46 each |
| 499+ | £4.40 each |
| 999+ | £4.28 each |
In Stock
| d | = | 15mm (Tolerance: 0/-0.008) |
| D | = | 26mm (Tolerance: 0/-0.009) |
| B | = | 12mm (Tolerance: 0/-0.12) |
| Radial internal clearance | = | 0-0.04mm |
| C | = | 9mm (Tolerance: 0/-0.24) |
| Da min | = | 21mm |
| da max | = | 18.4mm |
| dk | = | 22mm |
| Chamfer dimension r1s min | = | 0.3mm |
| Chamfer dimension r2s min | = | 0.3mm |
| a | = | 8° |
| Mass | = | 0.027 kg |
| Basic dynamic load, radial Cr | = | 17800 N |
| Basic static load, rating Cor | = | 44600 N |
